Difference Between Cyclic And Noncyclic Photophosphorylation: Noncyclic Photophosphorylation

Difference Between Cyclic And Noncyclic Photophosphorylation: Noncyclic Photophosphorylation

Edited By Irshad Anwar | Updated on Jul 02, 2025 06:58 PM IST

Table: Difference Between Cyclic And Noncyclic Photophosphorylation

Feature

Cyclic Photophosphorylation

Noncyclic Photophosphorylation

Energy Source

Light energy

Light energy

Electron Flow

Electrons cycle through Photosystem I (PS I) only

Electrons flow from Photosystem II (PS II) to Photosystem I (PS I)

ATP Production

Yes, ATP is produced

Yes, ATP is produced

NADPH Production

No, NADPH is not produced

Yes, NADPH is produced

Oxygen Release

No, oxygen is not released

Yes, oxygen is released as a byproduct of water-splitting

Photosystems Involved

Only Photosystem I (PS I)

Photosystem II (PS II) and Photosystem I (PS I)

Water Splitting

Not involved

Involves splitting of water

Electron Transport Chain (ETC)

Involves a shorter ETC associated with PS I

Involves a longer ETC associated with both PS II and PS I

Proton Gradient Formation

Yes, creates a proton gradient for ATP synthesis

Yes, creates a proton gradient for ATP synthesis

Purpose

Maintains ATP levels when NADPH is not needed

Provides ATP and NADPH required for the Calvin cycle

Location in Chloroplast

Thylakoid membranes of the chloroplast

Thylakoid membranes of the chloroplast

Impact on Photosynthesis

Provides a mechanism to balance ATP levels

Essential for the synthesis of glucose through the Calvin Cycle

Overall Efficiency

Less efficient for overall photosynthesis as it doesn’t produce NADPH

More efficient for overall photosynthesis as it provides both ATP and NADPH


Definition Of Photophosphorylation

Photophosphorylation is a process by which light energy is used in the light-dependent reactions for photosynthesis to synthesise ATP from ADP and inorganic phosphate. This activity is an essential part of the light energy conversion into chemical energy stored in the form of ATP and occurs within the membranes of thylakoids inside chloroplasts.

Photophosphorylation is a part of the photosynthetic process by which ATP and NADPH are produced, the essential energy carriers for the subsequent cycle of Calvin. These molecules carry energy and reduce power to drive carbon dioxide into glucose and other organic compounds supporting plants' energy needs for survival and growth.

There are two different pathways of photophosphorylation producing ATP in the light reactions of photosynthesis: cyclic and noncyclic photophosphorylation. Cyclic photophosphorylation involves only PS I, and it produces ATP without the generation of NADPH or oxygen. In contrast, noncyclic photophosphorylation involves both PS II and PS I and produces both ATP and NADPH with the release of oxygen as a byproduct. Both are essential steps of light-dependent reaction, although the two processes play different roles in supporting the overall photosynthetic process.

Cyclic Photophosphorylation

Cyclic photophosphorylation is light-dependent and the process by which ATP is produced using only Photosystem I and involves the cyclic flow of electrons. This does not yield NADPH or oxygen and seems to be mainly implicated in replenishing ATP levels when their levels are needed more than those of NADPH.

Definition And Process

  • Light Absorption: Light absorption by photosystem I excites electrons.

  • Electron Transport: The electrons transfer through a series of transport proteins in the thylakoid membrane.

  • ATP Synthesis: The energy from electron transport is used by ATP synthase to drive the synthesis of ATP.

  • Return of Electron: This step is completed by cycling back the electrons to Photosystem I.

Key Components

  • Photosystem I (PS I): This is the light-harvesting complex where electrons get excited.

  • Electron Transport Chain (ETC): This is a series of proteins that translocate excited electrons and generate a proton gradient.

  • ATP Synthesis: In this process, ATP is produced using the energy from the proton gradient.

Products Of Cyclic Photophosphorylation

  • ATP is produced through the cyclic electron flow.

  • Significance and Functions

  • ATP Supply: Provides ATP for other cellular processes.

  • Balancing ATP/NADPH: Maintains the level of ATP when there is excess NADPH.

Noncyclic Photophosphorylation

Noncyclic photophosphorylation involves both photosystems, PS II and PS I, and the overall result of this process is the formation of molecules of ATP and NADPH with the release of oxygen gas. It forms a part of the light-dependent reaction of photosynthesis and provides energy and reducing power to the Calvin cycle.

Definition And Process

  • Light Absorption: Light is absorbed by photosystem II and results in the splitting of the water molecule.

  • Electron Transport: The electrons are passed through the electron transport chain, thus creating a proton gradient.

  • ATP and NADPH Synthesis: The energy from this gradient of protons drives the process of synthesising ATP. These electrons reduce NADP+ into NADPH.

  • Oxygen Release: Water is split to release oxygen as a byproduct.

NEET Highest Scoring Chapters & Topics
Know Most Scoring Concepts in NEET 2024 Based on Previous Year Analysis.
Know More

Key Components

  • Photosystem II, PS II - A complex responsible for water-splitting and light absorption.

  • Photosystem I, PS I - A complex involved in producing NADPH.

  • Photolysis (Water Splitting): break-down of water to supply electrons

  • Electron Transport Chain: transport of electrons from PS II to PS I with concomitant formation of a proton gradient.

  • Reduction of NADP+: NADPH Formation

  • Noncyclic Photophosphorylation Products

  • ATP: Due to the electron transport chain, a proton gradient is formed.

  • NADPH: From the reduction of NADP+.

  • Oxygen: A by-product of water-splitting

Functions and Significance

  • ATP and NADPH Supply: The Calvin cycle is supplied with energy and reducing power.

  • Oxygen Production: This is necessary for respiration in aerobic organisms.

Role In Photosynthesis

  • Cyclic: Mainly maintains the concentration of ATP used by a wide range of cellular processes.

  • Noncyclic: Produces ATP and NADPH both of which are crucial for the Calvin cycle and hence overall photosynthetic efficiency.

Recommended Video On 'The Difference Between Cyclic And Noncyclic Photophosphorylation'


Frequently Asked Questions (FAQs)

1. What is the primary difference between cyclic versus non-cyclic photophosphorylation?

While cyclic photophosphorylation produces only ATP and involves Photosystem I, noncyclic photophosphorylation produces ATP, NADPH, and oxygen involving both Photosystem II and I.

2. Why isn't NADPH produced in cyclic photophosphorylation?

Being dependent on the action of Photosystem I alone cannot reduce NADP+ to NADPH, but works only in the production of ATP.

3. How does noncyclic photophosphorylation contribute to the Calvin Cycle?

Noncyclic photophosphorylation produces both ATP and NADPH, used in the Calvin Cycle to convert carbon dioxide into glucose.

4. Can both types of photophosphorylation happen simultaneously in plants?

Yes, because cyclic photophosphorylation will balance the concentration of ATP while non-cyclic photophosphorylation supplies ATP, NADPH and oxygen.

5. What are the environmental conditions that affect the efficiency of these processes?

Some of the factors affecting the efficiency of photophosphorylation include light intensity, accessibility of water, and temperature. Low light or stress in the water supply can lower both the rates of cyclic and noncyclic photophosphorylation.

6. Why is noncyclic photophosphorylation more common than cyclic photophosphorylation in most plants?
Noncyclic photophosphorylation is more common because it produces both ATP and NADPH, which are both required for the Calvin cycle, while cyclic photophosphorylation only produces ATP.
7. How does the production of ATP in noncyclic photophosphorylation differ from oxidative phosphorylation in cellular respiration?
Both use chemiosmosis to produce ATP, but noncyclic photophosphorylation uses light energy to create the proton gradient, while oxidative phosphorylation uses energy from electron carriers produced during glucose breakdown.
8. What is the role of plastoquinone in noncyclic photophosphorylation?
Plastoquinone is an electron carrier that transfers electrons from Photosystem II to the cytochrome b6f complex, contributing to the proton gradient across the thylakoid membrane.
9. What is the function of ferredoxin in noncyclic photophosphorylation?
Ferredoxin is an electron carrier that accepts electrons from Photosystem I and passes them to NADP+ reductase, which then reduces NADP+ to NADPH.
10. How does the energy of electrons change as they move through the noncyclic electron transport chain?
The energy of electrons decreases as they move through the chain, with the energy difference being used to pump protons and ultimately produce ATP and NADPH.
11. How does noncyclic photophosphorylation relate to the light-dependent reactions of photosynthesis?
Noncyclic photophosphorylation is the primary process of the light-dependent reactions, producing the ATP and NADPH needed for the Calvin cycle.
12. How does noncyclic photophosphorylation contribute to oxygen production?
Oxygen is produced as a byproduct when water molecules are split in Photosystem II at the beginning of noncyclic photophosphorylation.
13. What is the significance of P680 and P700 in noncyclic photophosphorylation?
P680 and P700 are the reaction center chlorophylls in Photosystem II and I respectively. They become excited by light energy, initiating the electron flow in noncyclic photophosphorylation.
14. What would happen if Photosystem II was inhibited during noncyclic photophosphorylation?
If Photosystem II was inhibited, the entire noncyclic process would stop. No oxygen would be produced, and neither ATP nor NADPH would be generated.
15. How does noncyclic photophosphorylation contribute to the acidification of the thylakoid space?
As electrons move through the electron transport chain, protons are pumped from the stroma into the thylakoid space, increasing its acidity.
16. Why is noncyclic photophosphorylation called "noncyclic"?
It's called "noncyclic" because electrons do not return to their starting point (Photosystem II) but instead follow a linear path from water to NADP+, unlike in cyclic photophosphorylation where electrons cycle back to Photosystem I.
17. Which photosystems are involved in noncyclic photophosphorylation?
Noncyclic photophosphorylation involves both Photosystem I and Photosystem II working together in a linear electron flow.
18. What are the main products of noncyclic photophosphorylation?
The main products are ATP (through chemiosmosis) and NADPH (through the reduction of NADP+).
19. How does water contribute to noncyclic photophosphorylation?
Water is split in Photosystem II during noncyclic photophosphorylation, providing electrons to replace those excited from chlorophyll molecules, and releasing oxygen as a byproduct.
20. What is the role of the electron transport chain in noncyclic photophosphorylation?
The electron transport chain transfers electrons from Photosystem II to Photosystem I, creating a proton gradient across the thylakoid membrane that drives ATP synthesis.
21. What is the main difference between cyclic and noncyclic photophosphorylation?
The main difference is that cyclic photophosphorylation involves only Photosystem I and produces only ATP, while noncyclic photophosphorylation involves both Photosystem I and II and produces both ATP and NADPH.
22. Why is noncyclic photophosphorylation considered the primary form of photophosphorylation in plants?
It's the primary form because it produces both ATP and NADPH, which are essential for the Calvin cycle (light-independent reactions) of photosynthesis.
23. How is NADPH formed during noncyclic photophosphorylation?
NADPH is formed when electrons from Photosystem I are transferred to NADP+ via the enzyme NADP+ reductase, reducing it to NADPH.
24. How does the Z-scheme relate to noncyclic photophosphorylation?
The Z-scheme is a visual representation of noncyclic photophosphorylation, showing the energy levels of electrons as they move from water through both photosystems to NADP+.
25. What happens to the protons (H+) during noncyclic photophosphorylation?
Protons accumulate in the thylakoid space, creating a concentration gradient. They then flow back through ATP synthase, driving the production of ATP.
26. How does the structure of the thylakoid membrane facilitate noncyclic photophosphorylation?
The thylakoid membrane contains all the necessary components (photosystems, electron carriers, ATP synthase) in a specific arrangement that allows for efficient electron flow and ATP production.
27. What would happen to noncyclic photophosphorylation if there was a shortage of NADP+ in the chloroplast?
Without sufficient NADP+, electrons would build up in the electron transport chain, potentially leading to the formation of harmful reactive oxygen species and a decrease in ATP production.
28. How does the light intensity affect the rate of noncyclic photophosphorylation?
Generally, as light intensity increases, the rate of noncyclic photophosphorylation increases until it reaches a saturation point where other factors become limiting.
29. What is the relationship between noncyclic photophosphorylation and carbon fixation in the Calvin cycle?
Noncyclic photophosphorylation provides the ATP and NADPH necessary for carbon fixation in the Calvin cycle, linking the light-dependent and light-independent reactions of photosynthesis.
30. How does the pH gradient created by noncyclic photophosphorylation drive ATP synthesis?
The pH gradient (proton gradient) created across the thylakoid membrane drives protons through ATP synthase as they move back to the stroma, powering the synthesis of ATP from ADP and inorganic phosphate.
31. What role does chlorophyll play in noncyclic photophosphorylation?
Chlorophyll molecules in both photosystems absorb light energy, becoming excited and donating electrons to the electron transport chain, initiating the process of noncyclic photophosphorylation.
32. How does the structure of ATP synthase relate to its function in noncyclic photophosphorylation?
ATP synthase has a rotor-like structure that spins as protons flow through it, causing conformational changes that catalyze the addition of inorganic phosphate to ADP, forming ATP.
33. What would happen to noncyclic photophosphorylation if the thylakoid membrane became leaky to protons?
If the membrane became leaky, the proton gradient would dissipate, reducing or preventing ATP production through chemiosmosis, though NADPH production could still occur.
34. How does the absorption spectrum of chlorophyll relate to the efficiency of noncyclic photophosphorylation?
The absorption spectrum of chlorophyll determines which wavelengths of light can initiate noncyclic photophosphorylation, with red and blue light being most effective.
35. What is the significance of the oxygen-evolving complex in noncyclic photophosphorylation?
The oxygen-evolving complex, associated with Photosystem II, catalyzes the splitting of water molecules, providing electrons for the photosynthetic electron transport chain and releasing oxygen as a byproduct.
36. How does noncyclic photophosphorylation contribute to the light-dependent regulation of the Calvin cycle?
The products of noncyclic photophosphorylation (ATP and NADPH) activate enzymes in the Calvin cycle, ensuring that carbon fixation occurs only when light energy is available.
37. What is the role of plastocyanin in noncyclic photophosphorylation?
Plastocyanin is a mobile electron carrier that transfers electrons from the cytochrome b6f complex to Photosystem I in the electron transport chain.
38. How does the redox potential of components in the electron transport chain relate to the direction of electron flow in noncyclic photophosphorylation?
Electrons flow from components with more negative redox potentials to those with more positive potentials, determining the direction of electron transport from water to NADP+.
39. What would happen to noncyclic photophosphorylation if there was a mutation in the gene encoding ATP synthase?
A mutation in ATP synthase could reduce or prevent ATP production, even if electron transport and NADPH production continued, potentially disrupting the balance of products needed for the Calvin cycle.
40. How does the stacking of thylakoids into grana affect noncyclic photophosphorylation?
Grana stacking increases the surface area for light absorption and brings the components of the electron transport chain into close proximity, enhancing the efficiency of noncyclic photophosphorylation.
41. What is the relationship between noncyclic photophosphorylation and photorespiration?
Noncyclic photophosphorylation produces ATP and NADPH used in photorespiration, but excessive photorespiration can deplete these products, reducing the efficiency of carbon fixation.
42. How does the concentration of CO2 indirectly affect noncyclic photophosphorylation?
Higher CO2 concentrations increase the rate of the Calvin cycle, which in turn increases the demand for ATP and NADPH, potentially stimulating noncyclic photophosphorylation.
43. What is the importance of the proton motive force in noncyclic photophosphorylation?
The proton motive force, created by the accumulation of protons in the thylakoid space, drives ATP synthesis as protons flow back through ATP synthase to the stroma.
44. How does the structure of the chloroplast facilitate noncyclic photophosphorylation?
The chloroplast's thylakoid membrane system provides a large surface area for light absorption and compartmentalization for efficient proton gradient formation and electron transport.
45. What would happen to noncyclic photophosphorylation if there was a shortage of electrons?
A shortage of electrons (e.g., due to insufficient water splitting) would slow down or stop the electron transport chain, reducing or halting both ATP and NADPH production.
46. How does temperature affect the rate of noncyclic photophosphorylation?
Temperature affects enzyme activity in the electron transport chain and ATP synthase. Generally, the rate increases with temperature up to an optimal point, after which it decreases due to enzyme denaturation.
47. What is the significance of the Q cycle in noncyclic photophosphorylation?
The Q cycle, occurring in the cytochrome b6f complex, helps pump additional protons into the thylakoid space, enhancing the proton gradient and increasing ATP production efficiency.
48. How does the production of NADPH in noncyclic photophosphorylation affect cellular redox balance?
NADPH production maintains a reduced environment in the chloroplast, necessary for carbon fixation and other biosynthetic processes, contributing to overall cellular redox balance.
49. What would happen to noncyclic photophosphorylation if there was a mutation affecting the oxygen-evolving complex?
A mutation in the oxygen-evolving complex would disrupt water splitting, reducing or stopping electron flow in Photosystem II, thereby inhibiting the entire noncyclic photophosphorylation process.
50. How does the light-harvesting complex contribute to noncyclic photophosphorylation?
Light-harvesting complexes increase the efficiency of light absorption by capturing light energy and transferring it to the reaction center chlorophylls in both photosystems.
51. What is the role of cytochrome f in noncyclic photophosphorylation?
Cytochrome f is part of the cytochrome b6f complex, which helps transfer electrons from plastoquinone to plastocyanin while pumping protons into the thylakoid space.
52. How does the concept of photoinhibition relate to noncyclic photophosphorylation?
Photoinhibition occurs when excess light energy damages the photosystems, particularly Photosystem II, reducing the efficiency of noncyclic photophosphorylation and overall photosynthesis.
53. What is the significance of state transitions in regulating noncyclic photophosphorylation?
State transitions involve the movement of light-harvesting complexes between photosystems to balance excitation energy, optimizing the efficiency of noncyclic photophosphorylation under changing light conditions.
54. How does the production of ATP and NADPH in noncyclic photophosphorylation relate to the concept of energy currency in cells?
ATP and NADPH produced by noncyclic photophosphorylation serve as energy currency and reducing power, respectively, driving various cellular processes, particularly carbon fixation in photosynthesis.
55. What would happen to noncyclic photophosphorylation if there was a blockage in electron flow between the two photosystems?
A blockage between photosystems would disrupt the entire process, preventing the formation of NADPH and reducing ATP production, ultimately halting the light-dependent reactions of photosynthesis.

Articles

Back to top
